vue实现登录滑动拼图验证的两种方法，纯前端组件验证以及前后端同时验证-前端-E先生的博客

vue实现登录滑动拼图验证的两种方法：

第一种是纯前端组件验证，只能区分是人为操作还是机器操作。

第二种是前后端同时验证，这种方法加上后端校验相对会更安全一些。（注：在最底部加上了同时兼容移动端的方法）

1、纯前端组件验证

效果如图：

实现步骤，先npm install：

npm install --save vue-monoplasty-slide-verify

在main.js引入

import Vue from 'vue';
import SlideVerify from 'vue-monoplasty-slide-verify';
Vue.use(SlideVerify);

在页面：

<slide-verify :l="42"
            :r="10"
            :w="310"
            :h="155"
            slider-text="向右滑动"
            @success="onSuccess"
            @fail="onFail"
            @refresh="onRefresh"
            ></slide-verify>
<div>{{msg}}</div>

js：

export default {
        name: 'App',
        data(){
            return {
                msg: '',
            }
        },
        methods: {
            onSuccess(){
                this.msg = 'login success'
            },
            onFail(){
                this.msg = ''
            },
            onRefresh(){
                this.msg = ''
            }
        }
    }

2、前后端同时验证

效果如图：

使用步骤和代码：

引入下方给的组件slider.vue到页面：

<!-- 拼图验证码 -->
  <div @click="onShow">开始验证</div>
    <div v-if="show">
      <Slider
        @getImg="getImg"
        @validImg="validImg"
        @close="onClose"
        :log="true"
      ></Slider>
    </div>
import Slider from "@/components/login/slider";
export default {
  components: {
    Slider
  },
  data() {
    return {
     show: false,
     loginForm: {}
    }
  },
   methods: {
    onShow() {
      this.show= true
    },
    onClose() {
      this.show = false;
    },
    // 获取滑动验证码（下方有格式截图）
    getImg(callback) {
      sliderCaptcha().then((res) => {
        callback(res.data.data);
      }, error => {
        callback(error);
      });
    },
    // 操作滑动后返回值，并传去后端验证
    validImg(movePercent, id, callback) {
      this.loginForm.code = movePercent; // 手动定位返回的值
      this.loginForm.key = id; // 后台返回的id，再传回去
      this.handleLogin(); // 登陆请求方法
      callback(false);
      this.show= true;
    },
 }

获取滑动验证码接口》后端返回值的格式：

下方是大佬贡献的组件，复制粘贴就可以用了：

slider.vue：

<template>
  <div>
    <div>
      <div>
        <div>
          <div>
            <span>请完成下列验证后继续</span>
          </div>
          <div>
            <img
              @click="reset"
            />
            <img
              @click="close"
            />
          </div>
        </div>
        <div>
          <div>
            <img

              :src="backgroupImg"
            />
          </div>
          <div

            :style="{left: `${moveX}px`}"
          >
            <img

              :src="moveImg"
            />
          </div>
        </div>
        <div>
          <div

            :style="{width: `${blcokLeft}px`}"
          >
            <div

              ref="block"
              @mousedown="start"
              :style="{left: `${blcokLeft}px`}"
            >
              <span></span>
            </div>
          </div>
        </div>
        <div

          v-if="loading"
        >
          <span>loading...</span>
        </div>
      </div>
    </div>
  </div>
</template>
<script>
// =========================================
// 父组件需要提供的方法 名称
// =========================================
/**
 * 获取滑块图片方法
 */
const GET_IMG_FUN = "getImg";
/**
 * 校验滑块图片方法
 */
const VALID_IMG_FUN = "validImg";
/**
 * 滑块窗口关闭事件监听
 */
const CLOST_EVENT_FUN = "close";
export default {
  data() {
    return {
      /**滑块背景图片 */
      backgroupImg: "",
      /**滑块图片 */
      moveImg: "",
      /**是否已经移动滑块 */
      startMove: false,
      /**滑块移动距离 */
      blcokLeft: 0,
      /**开始滑动的x轴 */
      startX: 0,
      /**划过的百分比 */
      movePercent: 0,
      /**验证码唯一ID */
      uuid: "",
      /**滑块移动的x轴 */
      moveX: 0,
      /** 加载遮罩标识 */
      loading: false
    };
  },
  props: {
    // 是否开启日志， 默认true
    log: {
      type: Boolean,
      required: false,
      default: true
    }
  },
  mounted() {
    this.getImg();
  },
  methods: {
    /**
     * 打印日志
     */
    printLog(msg, ...optionalParams) {
      if (this.log) {
        if (optionalParams && optionalParams.length > 0) {
          console.info(
            `滑块验证码[${msg}]`,
            optionalParams.length === 1 ? optionalParams[0] : optionalParams
          );
        } else {
          console.info(`滑块验证码[${msg}]`);
        }
      }
    },
    /**
     * 获取滑块图片
     */
    getImg() {
      this.loading = true;
      this.$emit(GET_IMG_FUN, data => {
        this.printLog(GET_IMG_FUN, data);
        this.loading = false;
        if (!data) return;
        console.log("data", data);
        this.backgroupImg = data.captcha.backgroundImage;
        this.moveImg = data.captcha.sliderImage;
        this.uuid = data.id;
      });
    },
    /**
     * 校验图片
     */
    validImg() {
      this.printLog(`滑块抬起`, this.movePercent);
      this.$emit(VALID_IMG_FUN, this.movePercent, this.uuid, data => {
        this.printLog(VALID_IMG_FUN, data);
        if (data === false) {
          this.reset();
        }
      });
    },
    /**
     * 重新生成图片
     */
    reset() {
      this.getImg();
      this.moveX = 0;
      this.movePercent = 0;
      this.startX = 0;
      this.blcokLeft = 0;
    },
    /**
     * 按钮关闭事件
     */
    close() {
      this.printLog("关闭按钮触发");
      this.$emit(CLOST_EVENT_FUN);
    },
    /**
     * 开始滑动
     */
    start(e) {
      this.startX = e.pageX;
      this.startMove = true;
      window.addEventListener("mousemove", this.move);
      window.addEventListener("mouseup", this.up);
    },
    /**
     * 滑块滑动事件
     */
    move(e) {
      if (!this.startMove) return;
      const moveX = e.pageX - this.startX;
      const movePercent = moveX / 280;
      if (moveX <= 0) {
        this.blcokLeft = 0;
        this.moveX = 0;
        this.movePercent = 0;
      } else if (moveX >= 0 && moveX <= 235) {
        this.blcokLeft = moveX;
        this.moveX = moveX;
        this.movePercent = movePercent;
      } else if (moveX >= 235) {
        this.blcokLeft = 235;
        this.moveX = 235;
        this.movePercent = movePercent;
      }
    },
    /**
     * 滑块鼠标抬起事件
     */
    up(e) {
      window.removeEventListener("mousemove", this.move);
      window.removeEventListener("mouseup", this.up);
      if (!this.startMove) return;
      this.startMove = false;
      this.validImg();
    }
  },
  /**
   * 销毁事件
   */
  beforeDestroy() {
    window.removeEventListener("mousemove", this.move);
    window.removeEventListener("mouseup", this.up);
  }
};
</script>
<style scoped>
.slider-mask {
  position: absolute;
  left: 0;
  top: 0;
  height: 40px;
  border: 0 solid #1991fa;
  background: #d1e9fe;
  border-radius: 2px;
}
.yidun_slider_icon {
  position: absolute;
  top: 50%;
  margin-top: -6px;
  left: 50%;
  margin-left: -6px;
  width: 14px;
  height: 10px;
  background-image: url(https://cstaticdun.126.net//2.13.7/images/icon_light.4353d81.png);
  background-position: 0 -13px;
  background-size: 32px 544px;
}
.inner-mv-img,
.inner-bg-img,
.title {
  -moz-user-select: none;
  -webkit-user-select: none;
  -ms-user-select: none;
  -khtml-user-select: none;
  user-select: none;
}
.slider {
  .mask {
    display: block;
    z-index: 998;
    background: rgba(0, 0, 0, 0);
    width: 310px;
    height: 280px;
  }
  .container {
    position: absolute;
    z-index: 999;
    width: 310px;
    height: 280px;
    margin: auto;
    background: rgba(255, 255, 255, 1);
    border-radius: 6px;
    box-shadow: 0px 0px 11px 0px rgba(153, 153, 153, 1);
    box-sizing: border-box;
    padding: 17px 15px;
    .title {
      font-size: 14px;
      color: #333;
      display: flex;
      justify-content: space-between;
      .button-group {
        img {
          width: 25px;
          height: 25px;
          cursor: pointer;
        }
      }
    }
    .img {
      width: 280px;
      height: 180px;
      position: relative;
      img {
        width: 100%;
      }
      .backgroup-img {
        position: absolute;
        left: 0;
        top: 0;
        width: 100%;
      }
      .move-img {
        width: 52.20338981px;
        position: absolute;
        left: 0;
        top: 0;
      }
    }
    .slide {
      width: 100%;
      height: 40px;
      border: 1px solid #e4e7eb;
      background-color: #f7f9fa;
      box-sizing: border-box;
      position: relative;
      &::before {
        position: absolute;
        content: "按住左边按钮移动完成上方拼图";
        display: flex;
        justify-content: center;
        align-items: center;
        font-size: 12px;
        color: #999;
        width: 100%;
        height: 100%;
        text-indent: 50px;
      }
      .block {
        width: 40px;
        height: 38px;
        background-color: #fff;
        box-shadow: 0 0 3px rgba(0, 0, 0, 0.3);
        display: flex;
        justify-content: center;
        align-items: center;
        position: absolute;
        left: 0;
        top: 0;
        cursor: pointer;
        background-size: 30px;
        background-repeat: no-repeat;
        background-position: center;
      }
    }
    .block:hover {
      background-color: #1991fa;
    }
    .block:hover .yidun_slider_icon {
      background-image: url(https://cstaticdun.126.net//2.13.7/images/icon_light.4353d81.png);
      background-position: 0 0;
      background-size: 32px 544px;
    }
    .loading {
      width: 100%;
      height: 100%;
      background: rgba(0, 0, 0, 0.3);
      position: absolute;
      top: 0;
      left: 0;
      border-radius: 6px;
      display: flex;
      justify-content: center;
      align-items: center;
      color: #fff;
    }
  }
}
</style>

如果想兼容移动端，可以做以下修改：

1、修改上面的组件，加上touchstart、touchmove、touchend方法

<div
  ref="block"
  @mousedown="start"
  @touchstart="touchstart"
  @touchmove="touchmove"
  @touchend="touchend"
  :style="{left: `${blcokLeft}px`}"
>
  <span></span>
</div>

js也加上以下几个方法，就可以了：

// 移动端 - 开始触屏
touchstart(e) {
  this.startX = e.changedTouches[0].screenX;
  this.startMove = true;
},
// 移动端 - 开始滑动
touchmove(e) {
  if (!this.startMove) return;
  const moveX = e.changedTouches[0].screenX - this.startX;
  const movePercent = moveX / 280;
  if (moveX <= 0) {
    this.blcokLeft = 0;
    this.moveX = 0;
    this.movePercent = 0;
  } else if (moveX >= 0 && moveX <= 235) {
    this.blcokLeft = moveX;
    this.moveX = moveX;
    this.movePercent = movePercent;
  } else if (moveX >= 235) {
    this.blcokLeft = 235;
    this.moveX = 235;
    this.movePercent = movePercent;
  }
},
// 移动端 - 结束滑动
touchend(e) {
  if (!this.startMove) return;
  this.startMove = false;
  this.validImg();
},
